Спецификации

Процесор
Intel
Сокет на процесора
LGA1851 Socket
Чипсет
Intel B860
Форм фактор
Micro ATX Form Factor: 9.6-in x 8.3-in, 24.4 cm x 21.1 cm
Гаранция, месеци
36 месеца
Макс. брой инсталирани процесори
1
Максимално количество на инсталирана памет
128 GB
Тип памет
DDR
Скорост/честота на паметта
8333 MHz (O.C.), 6400 MHz, 6200 MHz (O.C.)
Предлага метод за проверка за грешки
Non-ECC
Графична карта
Intel® Xe LPG Graphics Architecture;2 x HDMI 2.1 TMDS/FRL 8G Compatible, support HDR, HDCP 2.3 and max. resolution up to 4K 120Hz
Интерфейси
1 x USB-C 3.2 Gen2x2 3 x USB 3.2 Gen 1 2 x USB 2.0 2 x HDMI 1 x LAN (Gigabit Ethernet) 1 x audio line-out - mini-jack 1 x audio line-in - mini-jack 1 x microphone - mini-jack
Конектори
1 x SPI TPM Header;1 x Power LED and Speaker Header;1 x RGB LED Header;3 x Addressable LED Headers;1 x CPU Fan Connector (4-pin) (Smart Fan Speed Control);2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control);1 x AIO Pump Fan Connector (4-pin) (Smart Fan Speed Control);1 x 24 pin ATX Power Connector;1 x 8 pin 12V Power Connector;2 x USB 2.0 Headers (Support 4 USB 2.0 ports);1 x USB 3.2 Gen1 Headers (Supports 2 USB 3.2 Gen1 ports);1 x Front Panel Type C USB 3.2 Gen1 Header
Вградено аудио
HD Audio (8-channel)
Аудио кодек
Realtek ALC897
Слотове
1 x CPU 2 x DIMM 288-pin 1 x PCIe 4.0 x16 2 x PCIe 4.0 x1 1 x M.2 socket (2230 M.2 Key E slot) 2 x M.2 socket (2280 M.2 Key M slot)
Интерфейс Serial ATA
SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 PCIe 5.0 -connectors: 1 x Blazing M.2 PCIe 4.0 -connectors: 1 x Hyper M.2
Вграден LAN
Realtek RTL8111H
Ширина
24.4 cm
Дълбочина
21.1 cm
Други
5+1+1+1+1 Phase Power Design, ASRock Intel 4-Layer Memory POOL (Planes on Outer Layers) Technology, BIOS FlashBack button, ASRock Auto Driver Installer, Intel Hybrid Technology, Intel Turbo Boost Max Technology 3.0, Intel Thermal Velocity Boost (TVB), CUDIMM support, ASRock EZ Mode, ASRock Full HD UEFI, ASRock My Favorites in UEFI, ASRock Instant Flash, 6 Layer PCB, ASRock Polychrome RGB, DIY Friendly Design, chipset heatsink
