Спецификации
- ПроцесорAMD
- Сокет на процесораSocket AM4
- ЧипсетAMD A520
- Форм факторMini-ITX
- Гаранция, месеци24 месеца
- Макс. брой инсталирани процесори1
- Максимално количество на инсталирана памет64 GB
- Тип паметDDR4
- Скорост/честота на паметта2400 MHz, 2133 MHz, 2667 MHz, 2933 MHz, 3200 MHz, 3466 MHz (O.C.), 3600 MHz (O.C.), 3733 MHz (O.C.), 3800 MHz (O.C.), 3866 MHz (O.C.), 4000 MHz (O.C.), 4133 MHz (O.C.), 4200 MHz (O.C.), 4266 MHz (O.C.), 4333 MHz (O.C.), 4400 MHz (O.C.), 4466 MHz (O.C.), 4533 MHz (O.C.), 4600 MHz (O.C.)
- Слотове памет2
- Форм фактор на паметтаDIMM 288-pin
- Предлага метод за проверка за грешкиNon-ECC, ECC
- Характеристики на паметтаTwo DDR Channels
Небуферирана
XMP - Графична карта- Integrated AMD Radeon™ Vega Series Graphics in Ryzen Series APU*; - DirectX 12, Pixel Shader 5.0; - Shared memory default 2GB. Max Shared memory supports up to 16GB.**; - Dual graphics output: support HDMI and DisplayPort 1.4 ports by independent display controllers; - Supports HDMI 2.1 with max. resolution up to 4K x 2K (4096x2160) @ 60Hz; - Supports DisplayPort 1.4 Input with max. resolution up to 5K (5120x2880)@120Hz; - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.1 Port (Compliant HDMI monitor is required); - Supports HDR (High Dynamic Range) with HDMI 2.1; - Supports HDCP 2.3 with HDMI 2.1 and DisplayPort 1.4 Ports; - Supports 4K Ultra HD (UHD) playback with HDMI 2.1 and DisplayPort 1.4 Ports; - Supports Microsoft® PlayReady
- Интерфейси1 x PS/2 keyboard / mouse 1 x LAN (Gigabit Ethernet) 1 x DisplayPort 1 x HDMI 2 x USB 2.0 3 x USB 3.2 Gen 1 1 x audio line-in - mini-jack 1 x audio line-out - mini-jack 1 x microphone - mini-jack 1 x USB-C Gen1
- Конектори- 1 x RGB LED Header*; - 1 x Addressable LED Header**; - 1 x CPU Fan Connector (4-pin)***; - 2 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)****; - 1 x 24 pin ATX Power Connector; - 1 x 8 pin 12V Power Connector; - 1 x Front Panel Audio Connector; - 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection); - 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection)
- PS/21
- DisplayPort1
- USB 3.23 (USB 3.2 (type A)); 1 (USB 3.2 (type C))
- Вградено аудиоHD Audio (8-channel)
- Аудио кодекRealtek ALC887
- Аудио интерфейс3 (3.5 мм мини жак)
- Слотове1 x CPU 2 x DIMM 288-pin 1 x PCIe 3.0 x16 1 x M.2 socket (Key E)
- Слотове PCI-E X161
- Интерфейс Serial ATASATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 SATA-600 / PCIe 3.0 -connectors: 1 x Ultra M.2
- Вграден LANRealtek RTL8111H
- Тип захранващ конектор24+8 pin
- Височина170 мм
- Ширина17 cm
- Дълбочина17 cm
- ДругиASRock Super Alloy, Premium 60A Power Choke, Sapphire Black PCB, High Density Glass Fabric PCB, ASRock Ultra M.2, ASRock Full Coverage M.2 Heatsink, ASRock Full Spike Protection, ASRock APP Shop, ASRock Live Update, 8 Phase Power Design, 15µ Gold Contact, Energy Efficient Ethernet 802.3az, Preboot eXecution Environment (PXE), All-Solid Capacitor motherboard Design, ASRock Full HD UEFI, ASRock Instant Flash, ESD Protection
- Wi-Fi Antenna2
