Enhanced connectivityWith a variety of interfaces including VGA, HDMI, DisplayPort, USB-C 3.2 Gen 1, and USB 3.2 Gen 1, this motherboard offers versatile connectivity options for a wide range of peripherals and displays.Robust storage solutionsEquipped with multiple storage interfaces such as Hyper M.2, Ultra M.2, and Serial ATA-600 (RAID), the motherboard provides flexible storage solutions, supporting high-speed data transfer and RAID configurations for enhanced data integrity and performance.High-speed memory supportSupporting DDR5 SDRAM at speeds up to 7200 MHz (O.C.), the motherboard enables faster data processing and improved system performance, making it suitable for demanding applications and gaming.Advanced networkingFeaturing a 2.5 Gigabit Ethernet controller, the motherboard offers high-speed network connectivity, ensuring smooth online gaming, streaming, and fast data transfers.Comprehensive cooling and protectionWith ESD Protection and a 7+1+1 Phase Power Design, the motherboard ensures stable power delivery and protects against electrical surges, contributing to the longevity and reliability of the system.
Спецификации
- ПроцесорIntel
- Сокет на процесораLGA1700 Socket
- ЧипсетIntel B760
- Форм факторMicro ATX
- Гаранция, месеци36 месеца
- Макс. брой инсталирани процесори1
- Максимално количество на инсталирана памет96 GB
- Тип паметDDR
- Скорост/честота на паметта7200 MHz (O.C.)
- Слотове памет2
- Форм фактор на паметтаDIMM 288-pin
- Предлага метод за проверка за грешкиNon-ECC, ECC (operate in non-ECC mode)
- Характеристики на паметтаTwo DDR Channels
Небуферирана
XMP 3.0 - Графична карта- Intel® Xe Graphics Architecture (Gen 12); - 1 x HDMI 2.1 TMDS Compatible, supports HDCP 2.3 and max. resolution up to 4K 60Hz; - 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz; - 1 x D-Sub, supports max. resolution up to Full HD (1920x1080) 60Hz
- Интерфейси1 x VGA 1 x HDMI 1 x DisplayPort 1 x USB-C 3.2 Gen 1 3 x USB 3.2 Gen 1 2 x USB 2.0 1 x LAN (2.5Gigabit Ethernet) 1 x microphone - mini-jack 1 x audio line-in - mini-jack 1 x audio line-out - mini-jack
- Конектори- 1 x SPI TPM Header; - 1 x Chassis Intrusion and Speaker Header; - 1 x RGB LED Header*; - 3 x Addressable LED Headers**; - 1 x CPU Fan Connector (4-pin)***; - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)****; - 2 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)*****; - 1 x 24 pin ATX Power Connector; - 1 x 8 pin 12V Power Connector; - 1 x Front Panel Audio Connector; - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports); - 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
- VGA1 (15-pin D-sub)
- DisplayPort1
- USB 3.21 (USB 3.2 (type C)); 3 (USB 3.2 (type A))
- Вградено аудиоHD Audio (8-channel)
- Аудио кодекRealtek ALC897
- Аудио интерфейс3 (3.5 мм мини жак)
- Слотове1 x CPU 2 x DIMM 288-pin 1 x PCIe 4.0 x16 2 x PCIe 3.0 x1 1 x M.2 socket (2230 M.2 Key E slot) 1 x M.2 socket (2260/2280 M.2 Key M slot) 1 x M.2 socket (2280 M.2 Key M slot)
- Слотове PCI-E X161
- Слотове PCI-E X12
- Интерфейс Serial ATASATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 PCIe 4.0 -connectors: 1 x Hyper M.2 PCIe 3.0 -connectors: 1 x Ultra M.2
- Вграден LANRealtek RTL8125BG
- Тип захранващ конектор24+8 pin
- Височина201 мм
- Ширина24.4 cm
- Дълбочина20.1 cm
- Други7+1+1 Phase Power Design, ASRock Intel 4-Layer Memory POOL (Planes on Outer Layers) Technology, ASRock Auto Driver Installer, ASRock EZ Mode, ASRock Full HD UEFI, ASRock My Favorites in UEFI, ASRock Instant Flash, ASRock Easy RAID Installer, Intel Adaptive Boost Technology (ABT), Intel Thermal Velocity Boost (TVB), Intel Turbo Boost Max Technology 3.0, Intel Hybrid Technology, ESD Protection, ASRock Polychrome RGB
