Спецификации
- Суич, типFixed Port
- Общ брой портове28
- Основни портове, тип24x10/100/1000Base-T
- Power Over Ethernet (PoE)IEEE 802.3af and IEEE 802.3at PoE Standard; PoE Capable Ports (Ports 1 to 24: Up to 30 W); PoE Power Budget: Max. 370 W
- Гаранция, м.99 месеца
- Uplink портове4x10GE SFP
- Свободни (10GB) слотовеNo
- Управляем (Managed)CLI, Telnet Server, TFTP Client, IPv6 Neighbor Discovery, Configurable MDI/MDIX, SNMP (Supports v1, v2c, v3), SNMP Trap, System Log, DHCP Client, D-Link Network Assistant support, SNTP, ICMPv6, IPv4/v6 Dual Stack, DHCP Auto Configuration, RMON v1
- Паралелна работа (Stackable)Virtual Stacking Support: D-Link Single IP Management, Up to 32 devices per virtual stack, Up to 20G stacking bandwidth; Physical Stacking: Supports Duplex Chain/Ring topology, Up to 40G stacking bandwidth full duplex, Up to 6 units per stack
- Fans2 x smart fans
- ЗахранванеInternal Universal Power Supply: 100 - 240 VAC, 50/60 Hz
- RoutingLayer 3 Lite
- Памет (Flash, RAM)-
- Капацитет за маршрутизиране/превключване, Gbps128 Gbps
- Пропускателна способност, Mpps95.24 Mpps
- MAC адреси16000 MAC address table size
- VLAN (брой, стандарти)802.1Q Tagged VLAN, 4K VLAN Groups, Configurable VID: 0~4094, GVRP, Asymmetric VLAN, Auto Voice VLAN, Auto Surveillance VLAN, MAC-based VLAN, Protocol-based VLAN
- QoS802.1p Quality of Service, Queue Handling (Strict Priority Queue(SPQ), Weighted Round Robin(WRR), Deficit Round Robin(DRR), SPQ+WRR), 8 queues per port, Bandwidth Control-Port-based (Ingress/Egress, min. granularity for 10/100/1000 BASE-T ports is 64Kb/s)
- L2 мрежови стандартиIEEE 802.3, IEEE 802.3u, IEEE 802.3ab, 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x, Spanning Tree Protocol: IEEE 802.1D STP, IEEE 802.1w RSTP, IEEE 802.1s MSTP; IEEE 802.3ad Link Aggregation, IEEE 802.3az Energy Efficient Ethernet
- L3 мрежови стандартиDefault Routing, Static Routing: 64 IPv4 Static Route Entries, 32 IPv6 Static Route Entries
- IPv6 functionalityIPv6 ready and supports various IPv6 functions such as MLD Snooping, IPv6 security features, and IPv6 Quality of Service (QoS), ensuring seamless integration with next generation networks. IPv4/v6 dual stack functionality
- СигурностPort Security, Broadcast/Multicast/Unicast Storm Control, Dynamic ARP Inspection, D-Link Safeguard Engine, DHCP Server Screening, ARP Spoofing Prevention, SSH, SSL, Traffic Segmentation, IP-MAC-Port Binding, DoS Attack Prevention, ACLs
