Спецификации

Суич, тип
Fixed Port
Основни портове, тип
8x 10/100/1000 Mbps half/full duplex RJ45 ports
Power Over Ethernet (PoE)
8x PoE/PoE+ RJ45 ports, 137W PoE power budget RJ45
Гаранция, м.
99 месеца
Uplink портове
2x10/100/1000Base-T; 802.3af PoE/802.3at PoE+
Свободни (10GB) слотове
-
Управляем (Managed)
Management via an intuitive and familiar CLI, embedded web server (GUI), SNMP-based management console application (including Dell OpenManage Network Manager), Telnet or serial connection
Паралелна работа (Stackable)
2x 1GbE SFP
Fans
Fanless
Захранване
External (Air flow: I/O to power supply; Pass through POE); External power adapter: 137W of POE power
Памет (Flash, RAM)
Flash memory: 1GB; Packet buffer memory: 1.5MB
Капацитет за маршрутизиране/превключване, Gbps
24Gbps
Пропускателна способност, Mpps
18Mpps
MAC адреси
16K
VLAN (брой, стандарти)
VLANs supported: 512; Protocol-based VLANs: Supported; Max VLAN interfaces with ACLs applied: 24; Standards: Dell Voice VLAN, 802.1Q VLAN Tagging, Double VLAN Tagging, GVRP, 802.1v Protocol-based VLANs, Dell RSTP-Per VLAN, 802.1X (Auto VLAN)
QoS
2474 DiffServ Field, 2475 DiffServ Architecture, 2597 Assured Fwd PHB, Dell L4 Trusted Mode (TCP/UDP), Dell UDLD, Dell Flow Based QoS Services Mode (IPv4/IPv6), Dell Port Based QoS Services Mode
L2 мрежови стандарти
802.3ab, 802.3ac, 802.3ad, 802.3ae, 802.1p, 802.3u, 802.3x, 802.3z, 802.1D, 802.1p,802.1Q, 802.1S, 802.1v, 802.1W
IPv6 functionality
ARP entries: 2048 (IPv4)/512 (IPv6), Max ACL rules per interface and direction (IPv6): 1021 ing/253 egr; General IPv6 protocols are supported
Сигурност
SMI, SNMP, MIB, TACACS+, HTTP/1.1, TLS v1, RADIUS, HTTP over TLS, SSHv2, SSL, 802.1x, IP Address Filtering, RSPAN
