Спецификации
- Суич, типFixed Port
- Общ брой портове52
- Основни портове, тип48x 10/100/1000Base-T
- Power Over Ethernet (PoE)-
- Гаранция, м.99 месеца
- Uplink портове4x10G SFP+ (10G Uplink, 25G available for stacking only)
- Свободни (10GB) слотове-
- Управляем (Managed)Cisco Business Dashboard; Cisco Business mobile app; Cisco Network Plug and Play (PnP) agent; Web user interface; SNMP; MIB; RMON; RSPAN; sFlow agent; DHCP; SCP; Other: Traceroute, single IP management, HTTP/HTTPS, SSH, RADIUS and etc.
- Паралелна работа (Stackable)Supports up to 8 switches in a stack. Up to 400 ports managed as a single system with hardware failover
- Fans1
- Захранване100-240V 50-60 Hz, internal, universal
- RoutingDynamic Layer 3 routing
- Памет (Flash, RAM)1GB SLC (Flash), 2 GB DDR4 (DRAM), 3MB (Packet buffer)
- Капацитет за маршрутизиране/превключване, Gbps176 Gbps
- Пропускателна способност, Mpps130.95 Mpps
- MAC адреси16 000 addresses
- VLAN (брой, стандарти)Support for up to 4093 VLANs simultaneously; Port-based and 802.1Q tag-based VLANs, MAC-based VLAN, protocol-based VLAN, IP subnet-based VLAN; Management VLAN; Private/Guest/unauthenticated/Auto surveillance/CPE/Voice/Dynamic/Multicast TV VLAN
- QoS8 hardware queues; Strict priority and Weighted Round-Robin (WRR); Class of service: Port-based, 802.1p VLAN priority-based, IPv4/IPv6 IP precedence/Type of Service (ToS)/DSCP-based; Queue assignment based on DSCP and Class of Service (802.1p/CoS); iSCSI
- L2 мрежови стандартиIEEE 802.3, IEEE 802.3u/ab/ad/z/x/af/at; IEEE 802.1D (STP)/1Q/p VLAN/w RSTP/s Multiple STP/X Port Access Authentication; RFC
- IPv6 functionalityIPv6 host mode, IPv6 over Ethernet, dual IPv6/IPv4 stack IPv6 neighbor and router discovery (ND), IPv6 stateless address auto-configuration; DAD; IPv6 QoS;l ACL; First Hop Security; Multicast Listener Discovery (MLD v1/2) snooping; MLD
- СигурностSSH v1 and v2, SCP, SSL, 802.1X: RADIUS authentication and accounting; Web-based authentication; STP; DHCP; IPSG; DAI; IPMB; SCT; SSD; Trustworthy systems; Private VLAN; Layer 2 isolation Private VLAN Edge; Port security; RADIUS/TACACS+; DoS prevention
