BUILT-IN RESILIENCYHigh-end fixed switching for Software-Defined Access, App hosting, high availability, assurance, and smart buildingsHIGH PERFORMANCE AND SCALABILITYSupport for high-density 10G and 40G uplinks with up to 480 Gbps of stacking bandwidth for robust performance and network expansion.ADVANCED SECURITYFeatures like Encrypted Traffic Analytics (ETA) and Cisco TrustSec provide comprehensive security, including Network Access Control (NAC) capabilities.UP TO 1TB OF STACKING BANDWIDTHWith Stackwise-1T, Catalyst 9300 switches are the industry's highest-density stacking bandwidth solution with the most flexible uplink architecture.CLOUD MANAGEMENT AND MONITORINGCloud management and monitoring provides the ability to manage or view Catalyst 9300 switch statistics, configuration, and troubleshooting capabilities in Meraki dashboard.
Спецификации
- Суич, типFixed Port
- Общ брой портове52
- Основни портове, тип48x 10/100/1000Base-T, copper
- Power Over Ethernet (PoE)No
- Гаранция, м.99 месеца
- Uplink портове4x10G/1G SFP+
- Свободни (10GB) слотовеNo
- Управляем (Managed)WebUI is an embedded GUI-based device-management; RMON I and II standards, SNMPv1, v2c, and v3
- Паралелна работа (Stackable)Stackwise-320 (C9300L-STACK-KIT)
- Fans3 field-replaceable fans and support (N+1) redundancy
- Захранване350W AC
- RoutingAdvanced
- Памет (Flash, RAM)8 GB memory, and 16 GB of flash and external USB 3.0 SSD pluggable storage slot (delivering up to 240GB of storage with an option SSD drive) to host containers
- Капацитет за маршрутизиране/превключване, Gbps176 Gbps; Switching capacity with stacking: 496 Gbps
- Пропускателна способност, Mpps130.95 Mpps; Forwarding rate with stacking: 369.05 Mpps
- MAC адреси32 000
- VLAN (брой, стандарти)VLAN IDs: 4094
- QoSQoS scale entries: 5120, Superior QoS includes granular wireless bandwidth management and fair sharing, 802.1p CoS and (DSCP field classification, Shaped Round Robin (SRR) scheduling, Committed Information Rate (CIR), and eight egress queues per port
- L2 мрежови стандартиIEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.1x-Re,v IEEE 802.3ad, IEEE 802.3a,e IEEE 802.3af, IEEE 802.3at
- IPv6 functionalityDual-stack support for IPv4/IPv6 and dynamic hardware forwarding table allocations, for ease of IPv4- to-IPv6 migration; IPv6 routing entries: 16 000; IPv6 routing (using OSPFv3 and BGPv6), ? IPv6 addressing
- СигурностEncrypted Traffic Analytics (ETA), AES-256 MACsec/IPSec encryption, Trustworthy solutions built with Cisco Trust Anchor Technologies; Umbrella DNS Integration
- ДругиЗадължителен е минимум 3-годишен лиценз DNA Essentials.
