BUILT-IN RESILIENCYHigh-end fixed switching for Software-Defined Access, App hosting, high availability, assurance, and smart buildingsHIGH PERFORMANCE AND SCALABILITYSupport for high-density 10G and 40G uplinks with up to 480 Gbps of stacking bandwidth for robust performance and network expansion.ADVANCED SECURITYFeatures like Encrypted Traffic Analytics (ETA) and Cisco TrustSec provide comprehensive security, including Network Access Control (NAC) capabilities.UP TO 1TB OF STACKING BANDWIDTHWith Stackwise-1T, Catalyst 9300 switches are the industry's highest-density stacking bandwidth solution with the most flexible uplink architecture.CLOUD MANAGEMENT AND MONITORINGCloud management and monitoring provides the ability to manage or view Catalyst 9300 switch statistics, configuration, and troubleshooting capabilities in Meraki dashboard.
Спецификации
- Суич, типFixed Port
- Общ брой портове28
- Основни портове, тип24x10/100/1000Base-T
- Power Over Ethernet (PoE)24 PoE+; Available PoE power: 505W
- Гаранция, м.99 месеца
- Uplink портове4x10/100/1000Base-T
- Свободни (10GB) слотовеNo
- Управляем (Managed)SNMPv1, SNMPv2c, and SNMPv3; RMON I and II standards; Internet Group Management Protocol (IGMP); CLI; TCP; UDP
- Паралелна работа (Stackable)Stacking support: StackWise-320; 320 Gbps; Optional Stacking hardware: C9300L-STACK-KIT; Number of members: 8; Supported stack members: Other C9300L SKUs with same license level
- Fansthree field-replaceable fans and support (N+1) redundancy
- ЗахранванеDual redundant power supplies, Default primary AC power supply: PWR-C1-715WAC-P
- RoutingLayer 3 Advanced
- Памет (Flash, RAM)Flash memory: 16 GB; 8 GB DRAM
- Капацитет за маршрутизиране/превключване, Gbps56 Gbps; Switching capacity with stacking: 376 Gbps
- Пропускателна способност, Mpps41.66 Mpps; Forwarding rate with stacking: 279.76 Mpps
- MAC адреси32000 MAC address
- VLAN (брой, стандарти)VLAN IDs: 4094; IEEE 802.1Q VLAN
- QoSGranular wireless bandwidth management and fair sharing,802.1p Class of Service (CoS) and Differentiated Services Code Point (DSCP) field classification,Shaped Round Robin (SRR) scheduling,Committed Information Rate (CIR), and eight egress queues per port
- L2 мрежови стандартиIEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3bz, IEEE 802.3ad, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.1x-Rev, IEEE 802.3x
- L3 мрежови стандартиIP unicast routing protocols: Static, Routing Information Protocol Version 1 [RIPv1], and RIPv2, RIPng, Open Shortest Path First [OSPF]
- IPv6 functionalityIPv6 routing (using OSPFv3 and EIGRPv6) is supported in hardware for maximum performance; IPv6 addressing is supported on interfaces with appropriate show commands for monitoring and troubleshooting
- СигурностEnhanced security with AES-128 MACsec encryption, policy-based segmentation, and trustworthy systems
- ДругиЗадължителен е минимум 3-годишен лиценз DNA Essentials.
