ENTERPRISE-GRADE RESILIENCYHigh-end fixed switching for Software-Defined Access, app hosting, high availability, assurance, and smart buildings, creating a resilient foundation for demanding enterprise access environments.POWERFUL PERFORMANCE & SCALABILITYHigh-density 10G and 40G uplink options with StackWise-480 provide up to 480 Gbps of stacking bandwidth for robust performance and network expansion.ADVANCED PROTECTIONAdvanced features such as Encrypted Traffic Analytics (ETA) and Cisco TrustSec provide comprehensive security, including Network Access Control (NAC) capabilities, strengthening visibility and control across users, endpoints, and network traffic.HIGH-CAPACITY STACKINGStackWise-480 delivers up to 480 Gbps of stacking bandwidth across compatible Catalyst 9300 members, supporting resilient scale and flexible uplink architectures.STREAMLINED CLOUD MANAGEMENTCloud management and monitoring provide visibility into Catalyst 9300 switch statistics, configuration, and troubleshooting through the Meraki dashboard, simplifying oversight, troubleshooting, and ongoing network optimization.
Спецификации
- Суич, типModular
- Общ брой портове48
- Основни портове, тип36x 100M/1G/2.5G + 12x Multigigabit (10G/5G/2.5G/1G/100M) ENERGY STAR certified
- Power Over Ethernet (PoE)UPOE (60W per port) & IEEE 802.3bt type3 on all ports (24-port switch) or up to 30 ports (48-port switch)
- Гаранция, м.99 месеца
- Uplink портовеModular Uplinks
- Свободни (10GB) слотове-
- Управляем (Managed)Cloud management and monitoring; WebUI
- Паралелна работа (Stackable)Designed for stacking switches as a single virtual switch, enabling customers to have a single management plane and control plane for up to 448 access ports.
- FansThree field-replaceable fans and support (N+1) redundancy.
- ЗахранванеRedundant; Default AC power supply: 1100W AC
- RoutingHigh-Performance IP routing; Total routed ports: 448
- Памет (Flash, RAM)DRAM: 8 GB; Flash: 16 GB; Packet buffer per SKU: 16 MB buffer for 24-or 48-port Gigabit Ethernet models
- Капацитет за маршрутизиране/превключване, Gbps580 Gbps, Switching capacity with stacking: 1060 Gbps
- Пропускателна способност, Mpps431.54 Mpps; Forwarding rate with stacking: 788.69 Mpps
- MAC адреси32 000
- VLAN (брой, стандарти)VLAN IDs: 4094; IEEE 802.1Q VLAN
- QoSQoS scale entries: 5 120; Superior QoS (802.1p Class of Service (CoS), DSCP, SRR, CIR)
- L2 мрежови стандартиIEEE 802.3 ab/z/bz/an/x
- L3 мрежови стандартиIEEE 802.1D, RMON I and II standards, SNMPv1, v2c, and v3
- IPv6 functionalityIPv6 routing entries: 16 000
- СигурностETA, SUDI, AES-256 MACsec encryption, IPsec encryption, Trustworthy solutions built with Cisco Trust Anchor Technologies; Cloud Security: Umbrella DNS Integration, ASAc
- ДругиNetwork Essentials
