Enhanced performanceHigh-performance motherboards are loaded with advanced features and advanced technologies to overwhelm any challenge at hand no matter whether you're a gamer, prosumer, or PC enthusiast.Extended heatsink designMSI extended PWM heatsink and enhanced circuit design ensures even high-end processors to run in full speed.Thickened copper PCBAn enhanced PCB design improves heat dissipation and performance reliability.Advanced lightning solutionThe advanced solution with high-capacity bandwidth for maximum transfer speed.Flash BIOS buttonSimply use a USB key to flash any BIOS within seconds, without installing a CPU, memory or graphics card.Front Type-C USB 3.2Compatible with an advanced PC chassis and perfect for external drives and other mobile devices.M.2 shield FROZRStrengthened built-in M.2 thermal solution keeps M.2 SSDs safe while preventing throttling, making them run faster.Optimized for water coolingDesigned to support the most popular all-in-one water cooling solutions on the market. A dedicated water pump PIN header supports up to 3 amp, giving you full control of the water pump speed. A clearly marked "keep-out-zone" allows for easy and safe installation and a perfect fit.Fully controllable in BIOS and softwareMSI motherboards let you manage speeds and temperatures for all your system and CPU fans. Total Fan Control allows you check your primary system characteristics in a simplified graphical interface. You can also set up to 4 temperature targets for CPU and motherboard, which will adjust the fan speeds automatically.
Спецификации
- ПроцесорAMD
- Сокет на процесораSocket AM4
- ЧипсетAMD B550
- Макс. брой инсталирани процесори1
- Максимално количество на инсталирана памет128 GB
- Тип паметDDR4
- Скорост/честота на паметта2400 MHz, 1866 MHz, 2133 MHz, 2800 MHz, 3000 MHz, 2666 MHz, 2933 MHz, 3466 MHz (O.C.), 3733 MHz (O.C.), 3600 MHz (O.C.), 3866 MHz (O.C.), 4000 MHz (O.C.), 4133 MHz (O.C.), 4400 MHz (O.C.), 4266 MHz (O.C.), 3200 MHz, 3066 MHz
- Предлага метод за проверка за грешкиNon-ECC, ECC (operate in non-ECC mode)
- Интерфейси1 x LAN (Gigabit Ethernet) 1 x audio line-in - mini-jack 1 x audio line-out - mini-jack 1 x microphone - mini-jack 1 x TOSLINK 2 x USB 3.2 Gen 1 1 x USB 3.2 Gen 2 1 x audio line-out (center/subwoofer) - mini-jack 1 x audio line-out (rear) - mini-jack 1 x USB-C Gen2 1 x PS/2 keyboard / mouse 4 x USB 2.0 1 x HDMI 1 x DisplayPort
- Вградено аудиоHD Audio (8-channel)
- Аудио кодекRealtek ALC892
- Слотове1 x CPU 4 x DIMM 288-pin 1 x PCIe 4.0 x16 1 x PCIe 3.0 x16 (x4 mode) 2 x PCIe 3.0 x1
- Интерфейс Serial ATASATA-600 -connectors: 6 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 SATA-600 / PCIe 4.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 PCIe 3.0 -connectors: 1 x M.2 - RAID 0 / RAID 1
- Вграден LANRealtek RTL8111H
- Ширина30.5 cm
- Дълбочина24.4 cm
- ДругиAMD CrossFireX technology support, MSI Audio Boost, Debug LED, MSI Mystic Light, M.2 Shield FROZR, pre-mounted I/O shield, MSI Core Boost, MSI PCIe Steel Slot
