Спецификации

Процесор
Intel
Сокет на процесора
LGA1700 Socket
Чипсет
Intel Z790
Форм фактор
ATX Form Factor;30.5 cm x 23.4 cm
Гаранция, месеци
36 месеца
Макс. брой инсталирани процесори
1
Максимално количество на инсталирана памет
192 GB
Тип памет
DDR
Скорост/честота на паметта
4800 MHz, 5000 MHz, 5200 MHz, 5400 MHz, 5600 MHz, 5800 MHz (O.C.), 6000 MHz (O.C.), 6200 MHz (O.C.), 6400 MHz (O.C.), 6600 MHz (O.C.), 6800 MHz (O.C.), 7000 MHz (O.C.), 7200 MHz (O.C.)
Предлага метод за проверка за грешки
Non-ECC, on-die ECC
Интерфейси
1 x HDMI 1 x DisplayPort 1 x aerial 1 x USB-C 3.2 Gen2x2 1 x USB 3.2 Gen 2 2 x USB 3.2 Gen 1 4 x USB 2.0 1 x LAN (2.5Gigabit Ethernet) 1 x PS/2 keyboard / mouse 1 x audio line-in - mini-jack 1 x audio line-out - mini-jack 1 x microphone - mini-jack
Вградено аудио
HD Audio (8-channel)
Слотове
1 x CPU 4 x DIMM 288-pin 1 x PCIe 5.0 x16 3 x PCIe 4.0 x16 (x4 mode) 1 x PCIe 3.0 x1 1 x M.2 socket (2242/2260/2280 M.2 Key M slot) 2 x M.2 socket (2242/2260/2280/22110 M.2 Key M slot) M.2 socket (Key E)
Интерфейс Serial ATA
SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 PCIe 4.0 -connectors: 2 x M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5 SATA-600 / PCIe 4.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5
M.2 слот
3 M.2 slots (Key M)
Поддръжка на RAID
Intel Rapid Storage Technology
Вграден LAN
2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax, Bluetooth 5.2
Ширина
30.5 cm
Дълбочина
23.4 cm
Други
ASUS OptiMem II, Intel Turbo Boost Max Technology 3.0, Intel Turbo Boost Technology 2.0, Preboot eXecution Environment (PXE), CrashFree BIOS 3, LANGuard, overvoltage protection, ASUS SafeSlot Core+, ASUS Stainless Steel Back I/O, ASUS Q-Design, Q-DIMM, Q-LED Core, Q-Slot, M.2 heatsink, VRM heatsink design, ASUS EZ DIY, ASUS ProCool, ASUS Aura Sync, ASUS 5X Protection III, 14+1 Phase Power Design
