Спецификации

Процесор
AMD
Сокет на процесора
Socket AM4
Чипсет
AMD B550
Форм фактор
ATX; 2oz Copper PCB
Тип памет
DDR4
Графична карта
Integrated AMD Radeon™ Vega Series Graphics in Ryzen Series APU* (Actual support may vary by CPU); - 1 x HDMI 2.1, supports HDR, HDCP 2.3, 4K Ultra HD (UHD) playback and max. resolution up to 4K 60Hz
Конектори
- 1 x SPI TPM Header; - 1 x Power LED and Speaker Header; - 1 x RGB LED Header; - 3 x Addressable LED Headers; - 2 x CPU Fan Connectors (4-pin) (Smart Fan Speed Control); - 4 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control); - 1 x 24 pin ATX Power Connector; - 1 x 8 pin 12V Power Connector (Hi-Density Power Connector); - 1 x Front Panel Audio Connector; - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports); - 1 x USB 3.2 Gen1 Header (Support 2 USB 3.2 Gen1 ports); - 1 x Front Panel Type C USB 3.2 Gen1 Header
Вградено аудио
7.1 CH HD Audio (Realtek ALC897 Audio Codec)
Слотове
AMD Ryzen series CPUs (Vermeer and Matisse); - 2 x PCIe x16 Slots (PCIE1: Gen4x16 mode; PCIE2: Gen3 x2 mode); AMD Ryzen series APUs (Cezanne and Renoir); - 2 x PCIe x16 Slots (PCIE1: Gen3x16 mode; PCIE2: Gen3 x2 mode); AMD Ryzen series APUs (Picasso); - 2 x PCIe x16 Slots (PCIE1: Gen3x8 mode; PCIE2: Gen3 x2 mode); - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module
Интерфейс Serial ATA
CPU:; - 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode (with Vermeer, Matisse) or Gen3x4 (32 Gb/s) mode (with Cezanne, Renoir and Picasso); Chipset:; - 1 x Ultra M.2 Socket (M2_2, Key M), supports type 2280 SATA3 6.0 Gb/s & PCIe Gen3x4 (32 Gb/s) modes; - 1 x M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen3x2 (16 Gb/s) mode; - 4 x SATA3 6.0 Gb/s Connectors
Вграден LAN
- 2.5 Gigabit LAN 10/100/1000/2500 Mb/s; - Dragon RTL8125BG; - Supports Dragon 2.5G LAN Software; - Smart Auto Adjust Bandwidth Control; - Visual User Friendly UI; - Visual Network Usage Statistics; - Optimized Default Setting for Game, Browser, and Streaming Modes; - User Customized Priority Control
Други
Rock-Solid Durability; - 8+2 Power Phase; - Pre-Installed I/O Shield; Ultrafast Connectivity; - 2.5G LAN, 802.11axe Wi-Fi 6E Module; EZ Troubleshooter; - ASRock Post Status Checker
