Спецификации

Суич, тип
Fixed Port
Общ брой портове
24
Основни портове, тип
24x10/100/1000Base-T
Power Over Ethernet (PoE)
No
Гаранция, м.
60 месеца
Uplink портове
0
Свободни (10GB) слотове
No
Управляем (Managed)
Built-in Web-based browser for simple configuration and management; Network Management: SNMP v1, v2, v3; RMON (1, 2, 3, 9); ICMP echo/echo reply; Syslog; IEEE 802.1AB LLDP; IEEE 802.1AB LLDP-MED
Паралелна работа (Stackable)
No
Fans
Fanless design
Захранване
Input voltage of AC: 100 - 240 V AC, 50/60 Hz; Max. power consumption: 15.1 (watt)
Routing
Layer 2 Only
Памет (Flash, RAM)
Packet Buffer: 525 KB
Капацитет за маршрутизиране/превключване, Gbps
48 Gbps
Пропускателна способност, Mpps
35.7 Mpps
MAC адреси
8000 MAC address table size
VLAN (брой, стандарти)
Port-based VLAN, IEEE 802.1Q VLAN tagging, IEEE 802.3ad LACP, Guest VLAN, Voice VLAN
QoS
IEEE 802.1p priority queues per port, IEEE 802.1p Queuing method (scheduler), Input priority mapping, Rate limiting per port (ingress/egress)
L2 мрежови стандарти
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x flow control, IEEE 802.3az EEE support, IEEE 802.1p CoS support, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s
L3 мрежови стандарти
-
IPv6 functionality
IPv6 over Ethernet, Dual-stack, ICMPv6, Neighbor discovery, Auto configuration, Static IPv6 address and prefix length, Static IPv6 default gateway, IPv6 duplicate address detection
Сигурност
IEEE 802.1x, Port security, Layer 2 MAC filtering, Static MAC forwarding, RADIUS, TACACS+, SSL, Management VLAN, CPU defense engine, DoS prevention
