Спецификации
- Суич, типFixed Port
- Общ брой портове28
- Основни портове, тип24x10/100/1000Base-T
- Power Over Ethernet (PoE)No
- Гаранция, м.99 месеца
- Uplink портове4 dual personality
- Свободни (10GB) слотовеNo
- Управляем (Managed)Web-based GUI (IPv4/IPv6); Command Line Interface (CLI) through Telnet or SSH; Telnet Server/Client (Support IPv4/IPv6); Command logging; SNMP; System log; RMON; LLDP; BootP/DHCP client; DHCP; SNTP
- Паралелна работа (Stackable)No
- FansFanless
- ЗахранванеInternal universal power supply: AC Input: 100 to 240 V AC, 50/60 Hz; Max. Power Consumption: 17.32 W
- RoutingLayer 3 Lite
- Памет (Flash, RAM)CPU Memory: 256 MB DDR3, Flash Memory: 32 MB
- Капацитет за маршрутизиране/превключване, Gbps56 Gbps
- Пропускателна способност, Mpps77.4 Mpps
- MAC адреси8000 MAC address table size
- VLAN (брой, стандарти)802.1Q tagged VLAN; VLAN groups: Max. 256; Port-based/Asymmetric/Voice/Auto surveillance VLAN; Port-based Q-in-Q; ISM VLAN (multicast VLAN); VLAN Translation
- QoSCoS based on: Switch port, DSCP; Bandwidth control - Port-based (ingress, egress, min. granularity 16 Kbps); Queue handling: Strict priority (SPQ), Weighted Round Robin (WRR); 8 outbound queues
- L2 мрежови стандартиIEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3z, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.3ad, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1X, IEEE 802.3ah
- L3 мрежови стандартиDefault Routing, Static Route: Max. 128 IPv4 entries, Max. 128 IPv6 entries
- IPv6 functionalityRFC1981 Path MTU Discovery; RFC2460 IPv6; RFC2461, 4861 Neighbor Discovery; RFC2462, 4862 IPv6 Stateless Address Auto-configuration; RFC2893, 4213 IPv4/IPv6 dual stack function
- СигурностPort security (Up to 64 MAC addresses per port); Smart IP-MAC-Port Binding; Broadcast/Multicast/Unicast storm control; IP inspection; DAD; D-Link Safeguard Engine; DoS attack prevention; Traffic segmentation; SSH
