Спецификации
- Суич, типFixed Port
- Общ брой портове48
- Основни портове, тип48x RJ45 10/100/1000Mb PoE+ (up to 30.8W) auto- sensing ports
- Power Over Ethernet (PoE)PoE+ (up to 30.8W)
- Гаранция, м.12 месеца
- Uplink портове2x 10GbE SFP+ ports, 2x GbE combo media ports
- Свободни (10GB) слотовеHot swappable expansion module supporting dual-port SFP+ or dual-port 10GBaseT
- Управляем (Managed)Management via an intuitive and familiar CLI, SNMP-based management console application (including Dell OpenManage Network Manager), Telnet or serial connection
- Паралелна работа (Stackable)2 rear stacking ports (21Gbps) supporting up to 84Gbps (full- duplex)
- FansRedundant variable speed fans
- Захранване1x 1100w AC PS, IO to PSU air
- RoutingLine-rate Layer 3 routing: IPv4 and IPv6
- Памет (Flash, RAM)256 MB
- Капацитет за маршрутизиране/превключване, Gbps260 Gbps
- Пропускателна способност, Mpps193 Mpps
- MAC адреси56K (80K in L2 scaled mode)
- VLAN (брой, стандарти)Layer 2 VLANs: 4K; 802.1Q VLAN Tagging, Double VLAN Tagging, GVRP; Private VLAN support
- L2 мрежови стандартиIEEE compliance: 802.1AB, 802.1D, 802.1p, 802.1Q, 802.1Qbb, 802.1Qaz, 802.1s, 802.1w, 802.1x, 802.1x-2010, 802.3ab, 802.3ac, 802.3ad, 802.1ax, 802.3ae, 802.3af, 802.3at, 802.3az, 802.3u, 802.3x, 802.3z
- IPv6 functionalityStatic routes: 16K (IPv4)/8K (IPv6), Dynamic routes: 16K (IPv4)/8K (IPv6); IPv6 Router Alert Option, IPv6 Scoped Address Architecture, ICMP for IPv6, Neighbor Discovery and etc.
- СигурностRadius and IPv6, 802.1X with RADIUS, EAP, AES Cipher Algorithm in the SNMP User Base Security Model, SSHv2, Security Architecture for IPSec, IPSec Authentication Header, ESP Protocol
