CISCO CBS110 Unmanaged 16-port GE Switch - 0

CISCO CBS110 Unmanaged 16-port GE Switch - 1

SWITCH PORTS16 -Port 10/100/1000SIMPLEPlug-and-play without a need for IT know-how or support.POWER-OVER-ETHERNET8 PoE ports with 64W total power budgetPERFORMANCEGigabit Ethernet and integrated quality-of-service (QoS) intelligence optimize delay-sensitive services and improve overall network performance.INNOVATIVE DESIGNElegant and compact design, ideal for installation outside of wiring closet such as retail stores, open plan offices, and classrooms

Спецификации

Суич, тип
Fixed Port
Общ брой портове
16
Основни портове, тип
10/100/1000Base-T
Power Over Ethernet (PoE)
8 ports support PoE with 64W total PoE budget
Гаранция, м.
99 месеца
Uplink портове
-
Свободни (10GB) слотове
-
Управляем (Managed)
-
Паралелна работа (Stackable)
-
Fans
Fanless
Захранване
Internal (universal, 110-240VAC, 50-60 Hz)
Routing
-
Памет (Flash, RAM)
Packet Buffer: 2 MB; Flash 16 MB; CPU memory: 128 MB
Капацитет за маршрутизиране/превключване, Gbps
32 Gbps
Пропускателна способност, Mpps
23.8 Mpps
MAC адреси
8K
VLAN (брой, стандарти)
-
QoS
802.1p priority based, 4 hardware queues, priority queuing and Weighted Round-Robin (WRR)
L2 мрежови стандарти
IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab 1000BASE-T Gigabit Ethernet, IEEE 802.3z Gigabit Ethernet, IEEE 802.3x Flow Control, 802.1p priority, Energy Efficient Ethernet, 802.3af, Power over Ethernet
L3 мрежови стандарти
-
IPv6 functionality
-
Сигурност
Kensington lock slot
Други
CPU - 400 MHz ARM; Automatic Media Dependent Interface (MDI) and MDI crossover (MDI-X)
