BUILT-IN RESILIENCYHigh-end fixed switching for Software-Defined Access, App hosting, high availability, assurance, and smart buildingsHIGH PERFORMANCE AND SCALABILITYSupport for high-density 10G and 40G uplinks with up to 480 Gbps of stacking bandwidth for robust performance and network expansion.ADVANCED SECURITYFeatures like Encrypted Traffic Analytics (ETA) and Cisco TrustSec provide comprehensive security, including Network Access Control (NAC) capabilities.UP TO 1TB OF STACKING BANDWIDTHWith Stackwise-1T, Catalyst 9300 switches are the industry's highest-density stacking bandwidth solution with the most flexible uplink architecture.CLOUD MANAGEMENT AND MONITORINGCloud management and monitoring provides the ability to manage or view Catalyst 9300 switch statistics, configuration, and troubleshooting capabilities in Meraki dashboard.
Спецификации
- Суич, типModular
- Общ брой портове12
- Основни портове, тип12x 25G/10G/1G SFP28
- Power Over Ethernet (PoE)-
- Гаранция, м.99 месеца
- Uplink портовеModular Uplinks
- Свободни (10GB) слотове-
- Управляем (Managed)Cloud management and monitoring; WebUI
- Паралелна работа (Stackable)Designed for stacking switches as a single virtual switch, enabling customers to have a single management plane and control plane for up to 448 access ports.
- FansThree field-replaceable fans and support (N+1) redundancy.
- ЗахранванеRedundant; Default AC power supply: 715W AC
- RoutingHigh-Performance IP routing; Total routed ports: 448
- Памет (Flash, RAM)DRAM: 8 GB; Flash: 16 GB; Packet buffer per SKU: 16 MB buffer for 24-or 48-port Gigabit Ethernet models
- Капацитет за маршрутизиране/превключване, Gbps1400 Gbps, Switching capacity with stacking: 2400 Gbps
- Пропускателна способност, Mpps1041 Mpps; Forwarding rate with stacking: 1785 Mpps
- MAC адреси32 000
- VLAN (брой, стандарти)VLAN IDs: 4094; IEEE 802.1Q VLAN
- QoSQoS scale entries: 5 120; Superior QoS (802.1p Class of Service (CoS), DSCP, SRR, CIR)
- L2 мрежови стандартиIEEE 802.3 ab/z/bz/an/x
- L3 мрежови стандартиIEEE 802.1D, RMON I and II standards, SNMPv1, v2c, and v3
- IPv6 functionalityIPv6 routing entries: 16 000
- СигурностETA, SUDI, AES-256 MACsec encryption, IPsec encryption, Trustworthy solutions built with Cisco Trust Anchor Technologies; Cloud Security: Umbrella DNS Integration, ASAc
- ДругиNetwork Essentials
