ENTERPRISE-GRADE RESILIENCYHigh-end fixed switching for Software-Defined Access, app hosting, high availability, assurance, and smart buildings, creating a resilient foundation for demanding enterprise access environments.POWERFUL PERFORMANCE & SCALABILITYHigh-speed modular uplinks and StackWise-1T with up to 1 Tbps of stacking bandwidth support demanding applications, dense access, and future expansion.ADVANCED PROTECTIONAdvanced features such as Encrypted Traffic Analytics (ETA) and Cisco TrustSec provide comprehensive security, including Network Access Control (NAC) capabilities, strengthening visibility and control across users, endpoints, and network traffic.INDUSTRY-LEADING STACKINGStackWise-1T delivers up to 1 Tbps of stacking bandwidth across compatible Catalyst 9300X members, supporting resilient high-density access and efficient growth.STREAMLINED CLOUD MANAGEMENTCloud management and monitoring provide visibility into Catalyst 9300 switch statistics, configuration, and troubleshooting through the Meraki dashboard, simplifying oversight, troubleshooting, and ongoing network optimization.
Спецификации
- Суич, типModular
- Общ брой портове48
- Основни портове, тип48x 10G Multigigabit (10G/5G/2.5G/1G/100M), Data ports
- Power Over Ethernet (PoE)-
- Гаранция, м.99 месеца
- Uplink портовеModular Uplinks
- Свободни (10GB) слотове-
- Управляем (Managed)Cloud management and monitoring; WebUI
- Паралелна работа (Stackable)Designed for stacking switches as a single virtual switch, enabling customers to have a single management plane and control plane for up to 448 access ports.
- FansThree field-replaceable fans and support (N+1) redundancy.
- ЗахранванеRedundant; Default AC power supply: 715W AC
- RoutingHigh-Performance IP routing; Total routed ports: 448
- Памет (Flash, RAM)DRAM: 8 GB; Flash: 16 GB; Packet buffer per SKU: 16 MB buffer for 24-or 48-port Gigabit Ethernet models
- Капацитет за маршрутизиране/превключване, Gbps1760 Gbps, Switching capacity with stacking: 2760 Gbps
- Пропускателна способност, Mpps1309 Mpps; Forwarding rate with stacking: 2232 Mpps
- MAC адреси32 000
- VLAN (брой, стандарти)VLAN IDs: 4094; IEEE 802.1Q VLAN
- QoSQoS scale entries: 5 120; Superior QoS (802.1p Class of Service (CoS), DSCP, SRR, CIR)
- L2 мрежови стандартиIEEE 802.3 ab/z/bz/an/x
- L3 мрежови стандартиIEEE 802.1D, RMON I and II standards, SNMPv1, v2c, and v3
- IPv6 functionalityIPv6 routing entries: 16 000
- СигурностETA, SUDI, AES-256 MACsec encryption, IPsec encryption, Trustworthy solutions built with Cisco Trust Anchor Technologies; Cloud Security: Umbrella DNS Integration, ASAc
- ДругиNetwork Essentials
