Спецификации

Суич, тип
Fixed Port
Общ брой портове
8
Основни портове, тип
10/100/1000Base-T
Power Over Ethernet (PoE)
1x PoE input (802.3af) on port 1 or AC power
Гаранция, м.
60 месеца
Uplink портове
-
Свободни (10GB) слотове
-
Управляем (Managed)
Network PnP, Web user interface, Cisco Business mobile app, Cisco Business Dashboard, SNMP, MIBs, RMON, DHCP, CLI and etc.
Паралелна работа (Stackable)
-
Fans
Fanless
Захранване
100 to 240V 50 to 60 Hz, external
Routing
Layer 3 static routing
Памет (Flash, RAM)
512 MB (Flash), 1 GB DDR4 (DRAM), 1.5 MB (Packet buffer)
Капацитет за маршрутизиране/превключване, Gbps
16 Gbps
Пропускателна способност, Mpps
11.90 Mpps
MAC адреси
8000 addresses
VLAN (брой, стандарти)
Support for up to 255 active VLANs simultaneously; Port-based and 802.1Q tag-based VLANs, Management VLAN, Guest VLAN, Auto Surveillance VLAN (ASV), Voice VLAN
QoS
8 hardware queues; Port based, 802.1p VLAN priority based, IPv4/v6 IP precedence/Type of Service (ToS)/DSCP based, Differentiated Services (DiffServ), classification and re-marking ACLs, trusted QoS
L2 мрежови стандарти
IEEE 802.3, IEEE 802.3u/ab/ad/z/x/af/at; IEEE 802.1D (STP)/1Q/p VLAN/w RSTP/s Multiple STP/X Port Access Authentication; RFC
IPv6 functionality
IPv6 host mode, IPv6 over Ethernet, Dual IPv6/IPv4 stack, IPv6 Neighbor Discovery (ND), IPv6 stateless address auto-configuration, Path MTU discovery, DAD, ICMP v6, IPv6 over IPv4 network with ISATAP
Сигурност
SSL, SSH, IEEE 802.1X (authenticator role): RADIUS authentication, guest VLAN, single/multiple host mode, and single/multiple sessions; STP; SCT; SSD, Trustworthy systems, Port security, Storm control, DoS prevention, ACLs
