M.2 Shield FrozrWorld's fastest SSDs can start to lower performance when getting hot. Part of the motherboards heatsink design, M.2 Shield Frozr is the next generation M.2 thermal solution to avoid this by offering the best thermal protection to make sure that SSD maintains maximum performance.Fully controllable in BIOS and softwareMSI motherboards let you manage speeds and temperatures for all your system and CPU fans. Total Fan Control allows you check your primary system characteristics in a simplified graphical interface. You can also set up to 4 temperature targets for CPU and motherboard, which will adjust the fan speeds automatically.ConnectivityThe most important thing of DIY is expandability. MSI PRO series motherboards feature plenty possibility for prosumers' need. Stable LAN, faster storage and USB transfer speed and other expandable connectors are ready to enlarge your flexibility.Fast and future-ready storageMSI PRO series motherboards support all the latest storage standards, which allows users to connect any ultra-fast storage device. Higher efficiency makes your work easier.Experience moreMSI PRO series motherboards are designed to satisfy any professional workflow. Elevate your listening pleasure and enjoy extreme sound quality. Moreover, with years of experience in creating performance enhancing tools that are easy to use, only the highest quality applications are at your disposal. The extensive features let you fine-tune your system to deliver reliable maximum performance.PCB with 2oz thickened copperAn enhanced PCB design with 2oz thickened copper increases conductivity, improving heat dissipation and performance reliability especially during overclocking.A huge step of DDR performanceMSI OC LAB does not merely work hard on extreme overclocking. Compared to A320 motherboard memory A-XMP profile, MSI does have great improvement on performance and efficiency for A520 motherboards. Easy to enable A-XMP profile with auto power settings to get the best memory speed and stability.Core BoostCore Boost technology combines MSI's premium layout and optimized power design which allows for faster and undistorted current delivery to the CPU at pin-point precision. Not only supporting multi-core CPU, also creating the perfect conditions for your CPU overclocking.
Спецификации
- ПроцесорAMD
- Сокет на процесораSocket AM4
- ЧипсетAMD A520
- Макс. брой инсталирани процесори1
- Максимално количество на инсталирана памет64 GB
- Тип паметDDR4
- Скорост/честота на паметта2400 MHz, 1866 MHz, 2133 MHz, 2800 MHz, 3000 MHz, 2666 MHz, 2933 MHz, 3200 MHz, 3066 MHz, 3466 MHz (O.C.), 3733 MHz (O.C.), 3600 MHz (O.C.), 3866 MHz (O.C.), 4000 MHz (O.C.), 4133 MHz (O.C.), 4400 MHz (O.C.), 4266 MHz (O.C.), 4600 MHz (O.C.)
- Предлага метод за проверка за грешкиNon-ECC, ECC (operate in non-ECC mode)
- Интерфейси1 x LAN (Gigabit Ethernet) 1 x audio line-in - mini-jack 1 x audio line-out - mini-jack 1 x microphone - mini-jack 4 x USB 3.2 Gen 1 1 x PS/2 keyboard / mouse 2 x USB 2.0 1 x HDMI 1 x DisplayPort 1 x VGA
- VGAДа
- Вградено аудиоHD Audio (8-channel)
- Аудио кодекRealtek ALC892
- Слотове1 x CPU 2 x DIMM 288-pin 1 x PCIe x16 2 x PCIe 3.0 x1
- Интерфейс Serial ATASATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 SATA-600 / PCIe 3.0 -connectors: 1 x M.2
- Вграден LANRealtek RTL8111H
- Ширина24.4 cm
- Дълбочина21 cm
- ДругиM.2 Shield FROZR, MSI Audio Boost, MSI Core Boost, 2oz Copper PCB, Debug LED, Double ESD Protection, MSI Mystic Light Sync, Turbo M.2
