Enhanced connectivityWith a comprehensive array of ports including USB-C 3.2 Gen 2, HDMI, and DisplayPort, plus Wi-Fi 6E and Bluetooth 5.3 support, this motherboard ensures a wide range of connectivity options for various peripherals and high-speed Internet.Robust power designFeaturing 12+1 DrMOS power stages, ASUS DIGI+ VRM, and ProCool power connectors, the motherboard delivers precise power and improved performance stability, catering to the demands of high-end processors.Superior memory supportSupports DDR5 SDRAM with speeds up to 7800 MHz (O.C.), enabling faster data transfer rates and improved system performance, ideal for gaming and intensive multitasking.Advanced cooling optionsEquipped with M.2 heatsink, VRM heatsink design, and Water Pump Header, it ensures efficient cooling for sustained performance, even under heavy loads.Durable constructionTUF Protection, including SafeSlot Core+, TUF Chokes, and 5K black metallic capacitors, provides reliability and longevity, making it a solid foundation for your gaming rig or workstation.
Спецификации
- ПроцесорIntel
- Сокет на процесораLGA1700 Socket
- ЧипсетIntel B760
- Макс. брой инсталирани процесори1
- Максимално количество на инсталирана памет192 GB
- Тип паметDDR
- Скорост/честота на паметта4800 MHz, 5000 MHz, 5200 MHz, 5400 MHz, 5600 MHz, 5800 MHz (O.C.), 6000 MHz (O.C.), 6200 MHz (O.C.), 6400 MHz (O.C.), 6600 MHz (O.C.), 6800 MHz (O.C.), 7000 MHz (O.C.), 7800 MHz (O.C.)
- Предлага метод за проверка за грешкиNon-ECC, on-die ECC
- Интерфейси1 x DisplayPort 1 x HDMI 2 x aerial 1 x USB-C 3.2 Gen 2 1 x USB 3.2 Gen 2 2 x USB 3.2 Gen 1 4 x USB 2.0 1 x LAN (2.5Gigabit Ethernet) 1 x SPDIF out 1 x audio line-in - mini-jack 1 x microphone - mini-jack 1 x audio line-out/headphones - mini-jack 1 x audio line-out (rear) - mini-jack 1 x audio line-out (center/subwoofer) - mini-jack
- Вградено аудиоHigh Definition Audio (7.1-channel)
- Слотове1 x CPU 4 x DIMM 288-pin 1 x PCIe 5.0 x16 1 x PCIe 4.0 x4 1 x PCIe 3.0 x1 3 x M.2 socket (2242/2260/2280 M.2 Key M slot)
- Интерфейс Serial ATASATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 PCIe 4.0 -connectors: 3 x M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5
- Поддръжка на RAIDIntel Rapid Storage Technology
- Вграден LAN802.11a/b/g/n/ac/ax, 2.5 Gigabit Ethernet, Bluetooth 5.3
- Ширина24.4 cm
- Дълбочина24.4 cm
- ДругиASUS OptiMem II, Water Pump Header, ASUS DIGI+ VRM, Dr.MOS MOSFET, TUF ESD Guards, TUF LANGuard, overvoltage protection, ASUS SafeSlot Core+, ASUS Stainless Steel Back I/O, ASUS Q-Design, Q-DIMM, Q-LED, M.2 Q-Latch, Q-Slot, M.2 heatsink, VRM heatsink design, ASUS EZ DIY, ASUS ProCool, ASUS SafeDIMM, pre-mounted I/O shield, ASUS Aura Sync, ASUS TUF Protection, CrashFree BIOS 3, Preboot eXecution Environment (PXE), Windows 11 compatible, 12+1+1 Phase Power Design, ProCool Power Connector, 6 Layer PCB, Intel Turbo Boost Technology 2.0, Intel Turbo Boost Max Technology 3.0, TUF Chokes military-grade, TUF 5K black metallic capacitors, 12+1 DrMOS power stages, CPU Socket lever protector, ESD Guards, AURA RGB Lighting Control
