Спецификации

Процесор
Intel
Чипсет
Intel® H610 Chipset
Форм фактор
mATX Form Factor, 22.6 cm x 19.5 cm
Гаранция, месеци
24 месеца
Тип памет
DDR
Графична карта
1 x DisplayPort;1 x VGA port;1 x HDMITM port
Интерфейси
2 x USB 3.2 Gen 1(5G) ports (2 x Type-A);2 x USB 2.0 ports (2 x Type-A);1 x DisplayPort;1 x VGA port;1 x HDMITM port;1 x Realtek 1Gb Ethernet port;3 x Audio jacks;1 x PS/2 Keyboard (purple) port;1 x PS/2 Mouse (green) port
Конектори
Fan and Cooling related;1 x 4-pin CPU Fan header;1 x 4-pin Chassis Fan header;Power related;1 x 24-pin Main Power connector;1 x 4-pin +12V Power connector;Storage related;1 x M.2 slot (Key M);4 x SATA 6Gb/s ports;USB;1 x USB 3.2 Gen 1(5G) header supports additional 2 USB 3.2 Gen 1 ports;2 x USB 2.0 headers support additional 4 USB 2.0 ports;Miscellaneous;1 x Clear CMOS header;1 x Chassis Intrusion header;1 x COM Port header;1 x Front Panel Audio header (AAFP);1 x LPT header;1 x Speaker header;1 x SPI TPM header (14-1 pin);1 x 10-1 pin System Panel header
VGA
Да
Вградено аудио
Realtek 7.1 Surround Sound High Definition Audio CODEC;- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking;- Supports up to 24-Bit/192 kHz playback;Audio Features;- Audio Shielding;- Premium audio capacitors;- Dedicated audio PCB layers;* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output
Слотове
Intel® Core™ Processors (14th & 13th & 12th Gen): 1 x PCIe 4.0 x16 slot;Intel® H610 Chipset: 1 x PCIe 3.0 x1 slot
Интерфейс Serial ATA
Total supports 1 x M.2 slot and 4 x SATA 6Gb/s ports;Intel® H610 Chipset;M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 mode);4 x SATA 6Gb/s ports
M.2 слот
M.2 slot (Key M)
Вграден LAN
1 x Realtek 1Gb Ethernet
