Спецификации

Процесор
AMD
Сокет на процесора
AMD AM5
Чипсет
Socket AM4
Форм фактор
ATX, 8 Layer PCB
Тип памет
DDR
Графична карта
Integrated AMD RDNA™ graphics (Actual support may vary by CPU); - 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz
Конектори
1 x SPI TPM Header; 1 x Power LED and Speaker Header; 1 x RGB LED Header; 3 x Addressable LED Headers; 2 x CPU Fan Connectors (4-pin) (Smart Fan Speed Control); 3 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control); 1 x AIO Pump Fan Connector (4-pin) (Smart Fan Speed Control); 1 x 24 pin ATX Power Connector; 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector); 1 x Front Panel Audio Connector; 2 x USB 2.0 Headers (Support 4 USB 2.0 ports); 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports); 1 x Front Panel Type C USB 3.2 Gen1 Header
Вградено аудио
7.1 CH HD Audio (Realtek ALC897 Audio Codec)
Слотове
CPU:; - 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode; - 1 x PCIe 4.0 x16 Slot (PCIE4), supports x4 mode; Chipset:; - 2 x PCIe 4.0 x1 Slots (PCIE2 and PCIE3); - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module
Интерфейс Serial ATA
CPU:; - 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode; Chipset:; - 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode; - 4 x SATA3 6.0 Gb/s Connectors
Вграден LAN
2.5 Gigabit LAN 10/100/1000/2500 Mb/s; Dragon RTL8125BG; Supports Dragon 2.5G LAN Software; Smart Auto Adjust Bandwidth Control; Visual User Friendly UI; Visual Network Usage Statistics; Optimized Default Setting for Game, Browser, and Streaming Modes; User Customized Priority Control
Други
Superb Productivity; - PCIe Gen5 (Graphics, M.2); - Dual Channel DDR5; Rock-Solid Durability; - 9+2+1 Power Phase, Dr.MOS for VCore+SOC+MISC; - Pre-Installed I/O Shield; Ultrafast Connectivity; - 2.5G LAN, 802.11be Wi-Fi 7 Module; EZ Update; - BIOS Flashback Button; - ASRock Auto Driver Installer; EZ Troubleshooter; - ASRock Post Status Checker
